MARK II is out of stock now! New version of EF-E Smart Adapter (MARK IV) is available now.

This Smart AdapterTM has the following features:



• True electronic integration of aperture diaphragm - let camera automatically choose aperture in P or S exposure modes, or dial in yourself on the camera body in A or M modes.
• Powered by camera body. No external power source required.
• Wide open button (opposite of depth-of-field preview function) makes manual focusing easy.
• The tripod foot is detachable and compatible with Arca Swiss, Markins, Photo cam ball heads.
• High performance 32-bit processor and efficient switched-mode power supply.



Smart Adapter™ Mark II is NOT compatible with full-frame camera bodies such as A7, A7R and NEX-VG900. Please choose the newer Smart Adapter™ Mark III for full-frame Sony cameras.



Disclaimer: we are NOT licensed, approved or endorsed by Sony or Canon.

Compatibility

Supported

Not supported

EF lenses (see below for list of tested lenses) EF-S lenses (see note 1) Image stabilization (IS) (see note 2) Electronic manual focusing (e.g. EF 85/1.2L II and discontinued EF 50/1.0L) EXIF (focal length, aperture, zoom range) P, A, S, M exposure modes Autofocus (see autofocus support section below) Distance and zoom display on VG and FS series camcorders (see note 3) Auto magnify (see note 3) Contax N mount lenses modified to Canon EF by Conurus Contax 645 NAM-1 adapter modified to Canon EF by Conurus Sigma, Tamron and Tokina lenses in Canon EF mount (see note 4)

Lens correction such as peripheral shading, CA and distortion Focus confirmation "chip" (e.g. Dandelion) Stacking another lens mount adapter on top (see note 4) NEX-VG900

Note:

1. Vignetting at corners may occur for certain EF-S lenses because they are designed to cover a 1.6x crop image circle but Sony NEX has a 1.5x crop sensor.
2. Image Stabilization lens?requires adapter firmware version 02 or above.
3. Requires lenses supporting distance information.
4. A third party zoom lens may need to be registered with the Smart Adapter first in order to detect its maximum aperture. Autofocus is disabled for most third-party lenses.
5. For example, some improperly-made M42 screw mount adapters may cause a short-circuit with the electronic contacts of the Smart Adapter??and cause damage to the Smart Adapter??and/or camera body.?

Tested Camera Bodies

• NEX-FS700 (autofocus works only in photo mode, but is disabled in movie capture mode)
• NEX-FS100 (autofocus works only in photo mode, but is disabled in movie capture mode)
• NEX-EA50
• NEX-VG30
• NEX-VG20
• NEX-VG10
• NEX-7
• NEX-6
• NEX-5R
• NEX-5N
• NEX-5
• NEX-C3
• NEX-3

Tested Lenses

The following lenses have been tested for autofocus operation. Minimum firmware version required shown in parenthesis. Thanks to the community for reporting success with lenses shown in?bold.

Canon EF primes EF 14/2.8L II USM EF 24/1.4L II USM EF 24/2.8 IS USM EF 35/1.4L USM (Ver.19) EF 50/1.2L USM EF 85/1.2L II USM EF 85/1.8 USM (Ver.18) EF 100/2.8 USM macro (Ver.17) EF 135/2L USM (Ver.17) EF 200/2.8L II USM (Ver.17) EF 300/2.8L IS USM Extender EF 1.4x III Extender EF 2x (mark I)	Canon EF zooms EF 8-15/4L USM fisheye EF 17-40/4L USM EF 20-35/2.8L (Ver.18) EF 22-55/4-5.6 USM EF 24-70/2.8L USM II EF 28-80/3.5-5.6 II (Ver.18) EF 28-90/4-5.6 III EF 35-350/3.5-5.6L (Ver.18) EF 70-200/2.8L IS USM II EF 70-200/4L USM EF 70-200/4L IS USM EF 70-300/4-5.6L IS USM EF 70-300/4-5.6 IS USM EF 100-300/5.6 (non-L, not USM, push-pull zoom) (Ver.18) EF 100-400/4.5-5.6L IS USM	Canon EF-S EF-S 10-22/3.5-4.5 USM EF-S 17-55/2.8 IS USM EF-S 17-85/4-5.6 IS USM EF-S 18-55/3.5-5.6 EF-S 18-55/3.5-5.6 IS EF-S 18-135/3.5-5.6 IS EF-S 60/2.8 macro USM
Sigma DC 17-70/2.8-4 DC OS HSM (Ver.15) 30/1.4 DC HSM old version (Ver.18)	Tamron SP 24-70/2.8 Di VC USD A007 (Ver.15) SP 70-200/2.8 Di VC USD (Ver.17)	Tokina (full frame) 28-80/3.5-5.6 (Ver.18)
Tokina DX AT-X PRO SD 11-16/2.8 (IF) DX (Ver.15)

Note:

• Sigma 17-70/2.8-4 OS HSM may occasionally run into a focus accuracy issue at the telephoto end.

Manual Focus Only

The following lenses have been tested with previous firmware versions with manual focus, aperture control, image stabilization (if applicable) and EXIF support. Autofocus is supported only for those lenses marked with an asterisk (*), on NEX-5R/6, and with adapter firmware version 18 or above.

Canon EF primes EF 14/2.8L (mark I) EF 20/2.8 USM* EF 24/1.4L USM (mark I) EF 24/2.8 (old version, non-IS) TS-E 24/3.5L TS-E 45/2.8 EF 50/1.4 USM EF 50/1.8 II MP-E 65/2.8 macro EF 85/1.2L (mark I) EF 400/5.6L USM	Canon EF zooms EF 24-70/2.8L (mark I) EF 24-105/4L IS USM* EF 28-70/3.5-4.5 II  EF 35-80/4-5.6	Contax N modified by Conurus Vario-Sonnar 17-35/2.8 Vario-Sonnar 24-85/3.5-4.5 Vario-Sonnar 28-80/3.5-5.6  Planar 50/1.4 Planar 85/1.4 Makro-Sonnar 100/2.8 (Ver.21) NAM-1 adapter
Sigma (full frame) 24-70/2.8 EX HSM 24-70/2.8 EX DG HSM 50/1.4 DG HSM (Ver.17)* 50/2.8 DG Macro 70-200/2.8 EX DG Macro HSM 100-300/4	Sigma DC 12-24/4.5-5.6 EX ASPH 17-35/2.8-4 EX HSM ASPH 18-125/3.5-5.6 DC OS HSM 30/1.4 EX DC HSM new version (Ver.17)	Tamron 18-270/4.5-6.3 VC SP 28-75/2.8 SP 70-200/2.8 Di LD A001
Tokina AT-X PRO 28-70/2.8	Zeiss ZE ZE Distagon 15/2.8 ZE Distagon 21/2.8 ZE Distagon 35/2 ZE Makro-Planar 50/2 ZE Makro-Planar 100/2

This Smart Adapter is also compatible with fully manual lenses which have no electrical contacts. Customers have reported success with the following fully manual lenses.

• Samyang 35/1.4
• Zeiss CP.2 25mm/T2.9
• Zeiss CP.2 100mm/T2.1

Note:

1. 1. Lenses not listed above are not tested and they may or may not work. We do our best to resolve any compatibility issue you find but firmware updates are by factory service only and there is a nominal shipping/handling charge of $50.
   2. Mount lens on EF Extender 1.4x or 2x first before attaching both on Metabones Smart Adapter.
   3. Some samples of Sigma lenses may require adapter firmware Version 12 or above to function properly.
   4. Mount Contax 645 lens on modified NAM-1 first before attaching both on Metabones Smart Adapter.

Autofocus

Autofocus is supported, with the following known limitations.

• Autofocus speed is very slow and inadequate for most moving subjects. The autofocus speed is unfit for professional use for sure, and it would disappoint most enthusiasts.
• Only Canon-branded lenses introduced in or after 2006 are officially supported. Autofocus is disabled for older Canon lenses and most third-party lenses, including most Sigma, Tamron and Tokina lenses and all Contax N lenses modified by Conurus.
• On NEX camera bodies in camcorder form factor (e.g. FS series), autofocus may be available only in photo mode but not in movie capture mode.
• Continuous AF is not supported.
• DMF mode (direct manual focus) is not supported.
• For non-camcorder camera bodies (e.g. NEX-7), during movie capture, if the subject moves to a different distance, half-press the shutter release button to re-activate autofocus and lock onto the subject again. Since autofocus speed is slow, there may be visible disruption in the resulting footage.
• The first two autofocus attempts are used to calibrate the lens and as a result may not lock successfully on the target. Half-press the shutter release button again and autofocus will lock successfully.
• Autofocus may have difficultly locking onto subjects which are very close to the nearest focusing distance of the lens.
• Autofocus accuracy depends heavily on the working condition of the lens. Lenses with hidden problems which may not be apparent on Canon DSLRs will lead to inaccurate and unreliable autofocus on Sony NEX. Typical problems of this kind that we have seen include an unsmooth/erratic autofocus mechanism (e.g. getting stuck intermittently at a certain focusing distance), a faulty/worn-out distance encoder or other faulty/worn-out internal sensors.
• Autofocus is supported only on Mark III and Mark II Smart Adapters but does not work on the older Mark I version.
• Firmware version 14 or above is required. There is no firmware download but firmware update is a factory service procedure. If you have a lower version and require an update, please send your Smart Adapter back to us. There is a nominal shipping/handling charge.
